BMM Drip Proof Single-Phase Capacitor Run Motor

Customized manufacturing available

Quantity:
  • BMM152
  • BMM152

Our Products


BMM Drip Proof Single-Phase Capacitor Run Motor

BMM DRIPPOOF SINGLE-PHASE CAPACITOR RUN MOTOR(官网正文)

HP: 1/3HP-3HP

Pole: 2P, 4P

Capacitor Run

Frame: 56, 140T

Rolled steel, C-Face Kit

NEMA design: N

Service factor: 1.15

Insulation Class: F(UL approved)

Enclosure: ODP

IP Class: IP23

CSA&CUS,UL certified

Accept Auto Thermal Protector


Specifications

Model

Voltage

(V)

Frequency

(Hz)

Power

(hp)

Speed

(rpm)

NEMA FRAME

ENCL.

S.F

Full Load AMPS

Weight

(Kg)

BMMD56 1/3S2C-Y

115/208-230

60

1/3

3600

56

ODP

1.15

47/2.2-2.5

7.7

BMMD56 1/3S4C-V

115/208-230

60

1800

56

ODP

1.15

4.3/2.1-2.3

7.7

BMMD56 1/2S2C-V

115/208-230

60

1/2

3600

56

ODP

1.15

5.9/2.9-3.1

8.2

BMMD56 1/2S4C-Y

115/208-230

60

1800

56

ODP

1.15

5.8/2.8-3.0

9.1

BMMD56 3/4S2C-Y

115/208-230

60

3/4

3600

56

ODP

1.15

8.1/4.2-4.1

10.0

BMMD56 3/4S4C-Y

115/208-230

60

1800

56

ODP

1.15

8.1/4.0-4.2

11.3

BMMD56 1S2C-Y

115/208-230

60

1

3600

56

ODP

1.15

12/6.4-5.8

10.9

BMMD143T1S2C-Y

115/208-230

60

3600

143T

ODP

1.15

11.5/6.4-5.8

11.3

BMMD143T1S2A-Y

208-230/460

60

3600

143T

ODP

1.15

5.8-5.4/2.6

10.9

BMMD56 1S4C-Y

115/208-230

60

1800

56

ODP

1.15

11.5/6.0-5.7

16.3

BMMD143T1S4C-Y

115/208-230

60

1800

143T

ODP

1.15

11.5/6.0-5.7

16.8

BMMD143T1S4A-Y

208-230/460

60

1800

143T

ODP

1.15

4.8-5.3/27

16.3

BMMD56 1.5S2C-Y

115/208-230

60

1.5

3600

56

ODP

1.15

14.5/7.8-7.2

15.4

BMMD145T1.5S2C-Y

115/208-230

60

3600

145T

ODP

1.15

14.5/8.0-7.6

14.5

BMMD145T1.5S2A-Y

208-230/460

60

3600

145T

ODP

1.15

7.5-7.0/3.4

14.0

BMMD56 1.5S4C-Y

115/208-230

60

1800

56

ODP

1.15

15.5/8.1-7.6

19.0

BMMD145T1.5S4C-Y

115/208-230

60

1800

145T

ODP

1.15

15.5/8.1-7.6

19.5

BMMD145T1.5S4A-Y

208-230/460

60

1800

145T

ODP

1.15

7.1-67/3.4

19.0

BMMD56 2S2C-Y

115/208-230

60

2

3600

56

ODP

1.15

18/10.1-9.2

18.6

BMMD145T2S2C-Y

115/208-230

60

3600

145T

ODP

1.15

18/10.2-9.4

19.0

BMMD145T2S2A-Y

208-230/460

60

3600

145T

ODP

1.15

9.8-9.1/4.5

18.6

BMMD56 2S4C-V

115/208-230

60

1800

56

ODP

1.15

19.0/10-9.3

19.0

BMMD145T2S4C-V

115/208-230

60

1800

145T

ODP

1.15

19.0/10-9.3

19.5

BMMD145T2S4A-Y

208-230/460

60

1800

145T

ODP

1.15

9.8-9.1/4.5

19.0

BMMD56 3S2C-Y

115/208-230

60

3

3600

56

ODP

1.15

25/14.2-13

22.2

BMMD145T 3S2C-Y

115/208-230

60

3600

145T

ODP

1.15

25/14.2-13

22.7

BMMD145T3S2A-Y

208-230/460

60

3600

145T

ODP

1.15

14-12.5/6.5

22.2


Packing & Shipping

We use reliable packaging and logistics, for customer to receive the products in good condition. Also, we could customize according to your requirements.
