BMP 20 m3/h Vertical Stainless Steel Multi-Stage Centrifugal Electric Water Pump

25HP Vertical Stainless Steel Multi-Stage Centrifugal Electric Water Pump
Availability:
Quantity:
  • BMP606

  • BMP606


Our Products (1)


Product: BMP 20  m3/h Vertical Stainless Steel Multi-Stage Centrifugal Electric Water PumpMP606(官网正文)



Application Limits

Medium temperature: normal type:O℃ ~68℃ hot water type:O℃-120℃,

Ambient temperature:+40℃,

ax ambient pressure:1.0MPa,

Advisable to use motor of higher power in case that the density or viscosity of medium is above that of water.

pH: 5 to 8



















Specifications

Model

Power

Q

(m3/h)

12

14

16

18

20

22

24

26

28

32

Head Range

(m)

KW

HP

20-2(60Hz)

4

5.5

H(m)

38


37


35


32


29

24

24~38

20-3(60Hz)

5.5

7.5

58


56


53


50


45

38

38~58

20-4(60Hz)

7.5

10

78


75


72


67


60

51

51~78

20-5(60Hz)

11

15

98


94


90


85


75

64

64~98

20-6(60Hz)

11

15

118


113


108


102


91

77

77~118

20-7(60Hz)

15

20

138


133


127


119


107

91

91~138

20-8(60Hz)

15

20

158


153


146


137


123

105

105~158

20-10(60Hz)

18.5

25

198


193


185


172


155

133

133~198

20-2(50Hz)

2.2

3


27

25

24

23

22

20

18



18~27

20-3(50Hz)

4

5.5


40

38

37

35

33

30

27



27~40

20-4(50Hz)

5.5

7.5


54

51

49

47

44

41

37



37~54

20-5(50Hz)

5.5

7.5


67

62

60

58

55

50

45



45~67

20-6(50Hz)

7.5

10


81

75

73

70

66

61

55



55~81

20-7(50Hz)

7.5

10


95

89

86

82

77

71

65



65~95

20-8(50Hz)

11

15


109

102

99

94

89

82

75



75~109

20-10(50Hz)

11

15


136

128

124

118

111

103

95



95~136

20-12(50Hz)

15

20


164

154

149

142

133

124

114



114~164

20-14(50Hz)

15

20


192

180

174

166

156

145

133



133~192

20-17(50Hz)

18.5

25


234

219

212

202

190

177

162



162~234


Performance Curve

MP606-2


Outline Drawing

MP606-3

60Hz

MP606-3(1)

50Hz

Model

Dim.(mm)

B1

B2

B1+B2

D1

D2

20-2(60Hz)

411

355

766

240

190

20-3(60Hz)

491

430

921

275

210

20-4(60Hz)

536

430

966

275

210

20-5(60Hz)

611

500

1111

330

255

20-6(60Hz)

656

500

1156

330

255

20-7(60Hz)

701

500

1201

330

255

20-8(60Hz)

746

500

1246

330

255

20-10(60Hz)

836

560

1396

330

255

20-2(50Hz)

410

300

710

166

115

20-3(50Hz)

465

355

800

212

140

20-4(50Hz)

536

395

931

258

163

20-5(50Hz)

581

395

976

258

163

20-6(50Hz)

626

395

1021

258

163

20-7(50Hz)

671

395

1066

258

163

20-8(50Hz)

747

498

1245

315

251

20-10(50Hz)

837

498

1335

315

251

20-12(50Hz)

927

498

1425

315

251

20-14(50Hz)

1017

498

1515

315

251

20-17(50Hz)

1152

542

1694

315

251


Components & Materials

MP606-4

No. Component Material AISI/ASTM
1 Base Plate HT200 ASTM35B
2 Pump Base SUS304 AISI304
3 Inlet Fluid Director SUS304 AISI304
4 O-ring FPM
5 Lining SUS304 AISI304
6 Impeller SUS304
7 Fluid Director With   Bearings SUS304 AISI304
8 Bearing YG8
9 Fluid Director SUS304 AISI304
10 Outer Cylinder SUS304 AISI304
11 Pull-rod SUS304 AISI304
12 Long Round Sleeve SUS304 AISI304
13 Compress Nail FPM
14 Outlet Fluid Director SUS304 AISI304
15 Mechanical Seal YG6、FPM
16 Ball-shaped Lining SUS304 AISI304
17 Motor Standard Motor
18 Motor Base HT200 ASTM35B
19 Protection Blade SUS304 AISI304
20 Coupling QT 500 AISI304
21 Air Valve SUS304 AISI304
22 Pump Shaft SUS304 AISI304
23 Short Round Sleeve SUS304 AISI304
24 Pull-rod Steel 45#
25 Adjustable Bolt SUS304 AISI304

MP606-4(1)

No. Component Material AISI/ASTM
1 Pump Base HT200 ASTM35B
2 Inlet Fluid Director SUS304 AISI304
3 O-ring FPM
4 Lining SUS304 AISI304
5 Impeller SUS304 AISI304
6 Fluid Director With   Bearings SUS304 AISI304
7 Bearing YG8
8 Fluid Director SUS304 AISI304
9 Outer Cylinder SUS304 AISI304
10 Pull-rod SUS304 AISI304
11 Long Round Sleeve SUS304 AISI304
12 Compress Nail FPM
13 Outlet Fluid Director SUS304 AISI304
14 Mechanical Seal YG6、FPM
15 Motor Standard Motor
16 Motor Base HT200 ASTM35B
17 Protection Blade SUS304 AISI304
18 Coupling QT 500
19 Air Valve SUS304 AISI304
20 Pump Shaft SUS304 AISI304
21 Short Round Sleeve SUS304 AISI304
22 Adjustable Bolt SUS304 AISI304
23 Pull-rod Steel 45#
