WGB-NY
McMaster
WGB-NY
Product:7900N.m Wheel Gearbox For Irrigation System
Product:7900N.m Wheel Gearbox For Irrigation System
Technical Data
Max. Output Torque (N.m) | Ratio (i) | Output Shaft Diameter (inch) | Weight (Lbs) | Lubricating Oil Capacity (L) | |
WGB-NY | 7900 | 50 | 2.25 | 110 | 3.5 |
ITEM | PART | DESCRIPTION |
A | Output Shaft | Improved carbon structural steel withstand high output torque, the flange can install to large size tyre. |
B | Worm | Medium hardness with ZC1 circular arc tooth profile,high load capacity and long service life. |
C | Worm gear | High strength cast iron material,smooth transimission and long service life. |
D | Cover | High strength casting,and optimum design control the cover strength. |
E | Input Bearing | Large bearing ,long service life. |
F | Output Bearing | Accord to Timken standard, make sure service life. |
G | Seal on input | Seal,withstand high temperature and non-corresive, ensure unit without leakage. |
H | Seal on output | Seal,withstand high temperature and non-corresive, ensure unit without leakage. |
I | Shaft Protector | Zinc coating, non-corrosive. |
J | Shaft Protector | Shaft protector with high toughness & high impact resistance, not easy to damage. |
K | Key | High strength. |
L | Plug | Surface Zinc plated,Strong corrosion resistance,easy to remove. |
M | Bolt Set | High strength bolts make sure wheel in a good run condition. |
Product:7900N.m Wheel Gearbox For Irrigation System
Product:7900N.m Wheel Gearbox For Irrigation System
Technical Data
Max. Output Torque (N.m) | Ratio (i) | Output Shaft Diameter (inch) | Weight (Lbs) | Lubricating Oil Capacity (L) | |
WGB-NY | 7900 | 50 | 2.25 | 110 | 3.5 |
ITEM | PART | DESCRIPTION |
A | Output Shaft | Improved carbon structural steel withstand high output torque, the flange can install to large size tyre. |
B | Worm | Medium hardness with ZC1 circular arc tooth profile,high load capacity and long service life. |
C | Worm gear | High strength cast iron material,smooth transimission and long service life. |
D | Cover | High strength casting,and optimum design control the cover strength. |
E | Input Bearing | Large bearing ,long service life. |
F | Output Bearing | Accord to Timken standard, make sure service life. |
G | Seal on input | Seal,withstand high temperature and non-corresive, ensure unit without leakage. |
H | Seal on output | Seal,withstand high temperature and non-corresive, ensure unit without leakage. |
I | Shaft Protector | Zinc coating, non-corrosive. |
J | Shaft Protector | Shaft protector with high toughness & high impact resistance, not easy to damage. |
K | Key | High strength. |
L | Plug | Surface Zinc plated,Strong corrosion resistance,easy to remove. |
M | Bolt Set | High strength bolts make sure wheel in a good run condition. |
