| Input Voltage | 48V/36V/24V/12V DC |
| Load Capacity | 1200N |
| Speed | 5~120mm/s |
| Stroke | Customize |
| Type of Duty | 10%, 2 min. on / 18 min. off |
| Limit Switches | Inner |
| Operation Temperature | -15°C~45°C |
| Protect Class | IP65 |
| Wire Outlet Method | Side or bottom outlet (optional) |
| Minimum Order Quantity | 30 Sets |
details:
An industrial-grade solution for a wide range of applications. With IP65 rating, this reciprocating linear actuator is built to withstand harsh environments, making it suitable for industrial automation, robotics, automotive, agricultural machinery, and more.
Key features include:
Powerful DC brush motor capable of delivering up to 1200N of force
Available in various voltage options: 12V, 24V, 36V, and 48V, ensuring compatibility with different power systems IP65 protection rating, providing resistance against dust, water, and other environmental factors.
Reliable reciprocating motion for precise control and positioning Robust construction for long-lasting performance in demanding industrial settings.
Whether you need precise linear motion control for manufacturing equipment, agricultural machinery, or any other industrial application, our IP65-rated linear actuator with a DC brush motor is the ideal solution.
